Villa Style Home Plan
- Official Full Measurement Drawing Set
- Essential Drawings for your House
- Access to all your files in .PDF
- Free Home Delivery of Drawing Set

- In stock, ready to ship
- Inventory on the way
- Live Support: Call/Whatsapp on -91-8280-268-000
 Pack Details |
Essential | Advanced | |
Floor Plan | ![]() |
![]() |
Interior Furniture | ![]() |
![]() |
Dimension | ![]() |
![]() |
Exterior 3D View | ![]() |
Yes, 2 Realistic View |
2D Exterior View | ![]() |
Yes, 4- Sides |
Dimension for View | ![]() |
Yes |
Â
 Package Contains |
Essential | Advanced | |
Soft Copy | .PDF files ![]() |
.PDF files ![]() |
Hard Copy | 2 Sheets, A3 ISO | 8 Sheets, A3 ISO |
Â
Box Dimensions |
![]() |
Free Postal Delivery |
Â
Get all Essential Drawings to get started on your dream home.
Essential Package Includes :
1. Floor Plans in 2D - Soft-copy and Hard-copy
2. Floor Plans with Internal Furniture, Doors and Windows -Soft copy and Hard copy
Advanced Package Includes :
1. Everything in Basic Pack -Soft copy and Hard copy
2. 2D Exterior Views of all 4 Sides -Soft copy and Hard copy
3. 3D Exterior Realistic Views with Material -Soft copy and Hard copy
Â
NOTE: All Packages are available for Instant download as .PDF and Physical A3 High Gloss Print
Modern Home that advocates affluent living and simplicity. The 3 Bedroom Villa offers ample Private and Large Spaces for Family Rooms and Common Areas. They are designed for the aspiring Indian Family. The Design language emulates the Minimalist trends of the 21st Century. Ready to visualise your home needs?
All home plans and drawings support the complete construction of the design. Find the correct document set to help you budget and build your perfect home based on your need.
*Compliance: National Building Code 2016 | BIS
General House Information |
Building footprint |
4500 sq. ft. |
No. of Floors | 2 Level |
Width | 50 ft. |
Depth | 75 ft. |
Exterior Style |
Brick and Concrete Construction |
Urban |
Villa |
Features |
Bedrooms | Master Suite + 2 Bedrooms |
Bath | with Walkin Closet |
Living | Open Plan |
Kitchen | Island Style |
Dining | 6-8 Seater |
Utility | Available |
Store | Available |
Outdoor | Swimming Pool + Private Sit Out |
Garage | Semi Basement Enclosed |
Home & Ceiling Height |
First Slab Height | 12 ft |
Lintel Height | 2 ft 6 inch |
Framing Information |
Wall Framing | Brickwork |
Roof Framing | Concrete M20 grade |
