Sloped Roof Single Floor Home Plan
- Official Full Measurement Drawing Set
- Essential Drawings for your House
- Access to all your files in .PDF
- Free Home Delivery of Drawing Set

- In stock, ready to ship
- Inventory on the way
- Live Support: Call/Whatsapp on -91-8280-268-000
 Pack Details |
Essential | Advanced | |
Floor Plan | ![]() |
![]() |
Interior Furniture | ![]() |
![]() |
Dimension | ![]() |
![]() |
Exterior 3D View | ![]() |
Yes, 2 Realistic View |
2D Exterior View | ![]() |
Yes, 4- Sides |
Dimension for View | ![]() |
Yes |
Â
 Package Contains |
Essential | Advanced | |
Soft Copy | .PDF files ![]() |
.PDF files ![]() |
Hard Copy | 2 Sheets, A3 ISO | 8 Sheets, A3 ISO |
Â
Box Dimensions |
![]() |
Free Postal Delivery |
Â
Get all Essential Drawings to get started on your dream home.
Essential Package Includes :
1. Floor Plans in 2D - Soft-copy and Hard-copy
2. Floor Plans with Internal Furniture, Doors and Windows -Soft copy and Hard copy
Advanced Package Includes :
1. Everything in Basic Pack -Soft copy and Hard copy
2. 2D Exterior Views of all 4 Sides -Soft copy and Hard copy
3. 3D Exterior Realistic Views with Material -Soft copy and Hard copy
Â
NOTE: All Packages are available for Instant download as .PDF and Physical A3 High Gloss Print
Are you looking for an easy and affordable way to built your future home ? Ongrid Design Home Packs are just the answer you need. From figuring out the optimum size of house to deciding budget. This Drawing set from certified Architects and Designers will keep you covered.
![]() |
Land Type | Flat Terrain | Wet Climate |
Plot Size |
39 feet X 42 feet ( minimum ) 41 feet X 45 feet ( recommended ) |
Design for |
Family of 2 or 4 |
Construction Cost |
Rs.1000 - Rs.1200 per sqft.* |
A Kerala style home with sloped roof and open courtyard welcomes the monsoon with it's unique architecture style. The home plan is a 891 sq.ft in area with full service living configuration for a family.
Design Attributes |
Brick and Concrete Construction |
Country |
Farm House |
Home & Ceiling Height |
First Slab Height | 10 ft. |
Lintel Height | 2 ft. 6 inch |
Framing Information |
Wall Framing | Brickwork |
Roof Framing | Concrete M20 grade |
